ProductsFusesSolar PV FusesCylindrical PV Fuses PV4A10F 4A
PV4A10F 4A
PV4A10F 4A
PV4A10F 4A

PV4A10F 4A

Eaton Bussmann Cylindrical Solar/PV-Fuses: 4 Amps, 1000 Vdc/50kA, Operating Class: gPV, Size: 10x38mm, without Indicator

Non-returnable
₹75.00
Technical Documents
Catalogue PDF
Product Details

Features:

  • Specifically designed to protect and isolate Photovoltaic Strings
  • Capable of interrupting low overcurrents associated with faulted PV string arrays (reverse current, multi-array fault)
  • IEC® 60269-6, UL® Listed to 248-19 (File E335324)
  • CSA® File 53787, Class 1422-30 (1 to 15 A), CCC, RoHS compliant

Specifications
Technical Data
  • Manufacturer
    :
    Eaton Bussmann
  • Series
    :
    PV**A10F
  • Fuse Type
    :
    Cylindrical PV
  • Operating Class
    :
    gPV
  • Current Rating (A)
    :
    4A
  • Voltage Rating (Vdc)
    :
    1000 Vdc
  • DC Breaking Capacity (kA)
    :
    50 kA
  • Size
    :
    10x38mm
  • Pre-Arcing I2t Value A2s
    :
    9.5
  • Total I2t Value A2s
    :
    26.0
  • Power Loss (W)
    :
    1.5 W
  • Fuse Blown Indicator
    :
    NA
  • Standards
    :
    IEC® 60269-6; UL® Listed to 248-19 (File E335324); CSA® File 53787 Class 1422-30 (1 to 15 A); CCC; RoHS compliant
  • Approvals
    :
    IEC/UL/CCC/CSA/RoHS
  • Country of Origin
    :
    India
