ProductsFusesSolar PV FusesCylindrical PV Fuses SPXV30
SPXV30
SPXV30
SPXV30

SPXV30

Littelfuse Cylindrical Solar/PV-Fuses: 30 Amps, 1500 Vdc/30kA, Operating Class: gPV, Size: 10x85mm, without Indicator

Non-returnable
₹250.00
Technical Documents
Catalogue PDF
Product Details

Features:

  • Specifically designed for the protection of Photovoltaic (PV) Systems
  • Full range, fast-acting fuse helps eliminate common low-overload faults
  • Up to 50 kA interrupting rating
  • UL 248-19 Listed (File: E339112), UL 248-1
  • IEC 60269-6, RoHS compliant, CE

Specifications
Technical Data
  • Manufacturer
    :
    Littelfuse
  • Series
    :
    SPXV
  • Fuse Type
    :
    Cylindrical PV
  • Operating Class
    :
    gPV
  • Current Rating (A)
    :
    30A
  • Voltage Rating (Vdc)
    :
    1500 Vdc
  • DC Breaking Capacity (kA)
    :
    30 kA
  • Size
    :
    10x85mm
  • Pre-Arcing I2t Value A2s
    :
    3770.0
  • Total I2t Value A2s
    :
    6204.0
  • Power Loss (W)
    :
    7.16 W
  • Fuse Blown Indicator
    :
    NA
  • Standards
    :
    UL 248-19 Listed (File: E339112); UL 248-1; IEC 60269-6; RoHS Compliant; CE
  • Approvals
    :
    UL/IEC/CE/RoHS
  • Country of Origin
    :
    Mexico
